SHENYANG(SMTCL) Vertical Machining Center VMC 1100Q

Product description:
Q series machine tools is a new generation general vertical machining center launched by Genertec SMTCL through independent R&D and the combination of many years’ design and manufacture experience. Through professional design and using analytical software for scientific and rational analysis/optimization, as well as the validation and improvement by using advanced manufacturing/testing techniques, this product indicates superior machinability, which can satisfy the drilling and milling requirements of different components.


Product Detail

Product Tags

Specification

Item

Unit

VMC 1100Q

Table

Table size

mm

1300×610

Max.allowed loading

kg

1000

T slot size

mm×N

18×5

Machining range

X axis travel

mm

1100

Y axis travel

mm

620

Z axis travel

mm

600

Distence between
spindle nose to table

Max.

mm

720

Min.

mm

120

Distence between spindle center to guideway surface

mm

743

Spindle

Taper (7:24)

-

BT40

Speed

r/min

10000

Torque

N.m

35.8/70 (S2 15 Minutes)

Main motor power

kW

7.5/11

Drive type

-

Synchrono us belt

Tooling

Tool holder

-

MAS 403 BT40

Pull stud

-

MAS 403 40BT- 1

Feed

Rapid feed

X axis

m/min

48

Y axis

m/min

48

Z axis

m/min

48

Motor power(XYZ)

kW

3/3/3

Motor torque(XYZ)

Nm

20/20/20

Feeding speed

mm/min

1-20000

Toot Magazine

Type

-

Robot

Tool collection

-

Nearest tool selection

Magazine capacity

-

24

Max.tool length

mm

300

Max.tool weight

kg

7

Max.tool disk dia.

Full

mm

Φ80

Nearby

mm

Φ150

Tool change time

s

2.5

Distence between table to ground

mm

950

Machine weight

kg

6200

Electricity capacity

KVA

25

Overall Dimensions (L×W×H)

mm

2940× 3450×3050 (without conveyor)
