SHENYANG (SYMG) HTC40b1000 Precision CNC Machine Tool Slant Bed Lathe

Product Description

HTC40 series CNC slant lathe is a high-quality product designed and produced in accordance with the market and development needs by combining our experience in designing horizontal CNC horizontal lathes for many years. The newly designed host structure and reliable assembly process have made htc40 series machine tools fully upgraded. With stable and reliable product performance and innovative ergonomic design, htc40B series will undoubtedly become the best in the industry.

Send email to us Download as PDF

Product Detail

Product Tags

Model NO.	HTC40B/1000	After-sales Service	1 Year Service Parts After Shipment Date
Warranty	1 Year Service Parts After Shipment Date	Type	Horizontal Lathe
Processing Accessory	Chuck CNC Lathe	Guide Rail	Horizontal Guide Rail
Tool Holder	Single-tool Holder CNC Lathe	Power Source	Electric
Controlling Mode	CNC	Automatic Grade	Automatic
Setting Mode	Table	Precision	High Precision
Certification	CE	Condition	New
Max Swing Over Bed	560 mm	Cutting Length	1000 mm
Cutting Diameter	360 mm	Max Swing Over Slide Diameter	350 mm
Spindle Nose	A2-8	Spindle Bore	80 mm
Bar Through Diameter	50 mm	Speed	50-4000 R/Min
Max Output Torque	177 Nm	Steps	Stepless
Power	15(30min)/11(Rated) Kw	Diameter	8″
X-Axis Max Travel Speed	30 M/Min	Z-Axis Max Travel Speed	30 M/Min
X-Axis Travel	200 mm	Trademark	SHENYANG(SYMG)
Origin	Shenyang, China

Product Description

Specification

Item	Unit	HTC40B/1000
Working Length	mm	1000
Max Swing Over Bed	mm	Φ560
Cutting Length	mm	1000
Cutting Diameter	mm	Φ360
Max Swing Over Slide Diameter	mm	Φ350
Spindle Nose	-	A2-8
Spindle Bore	mm	Φ80
SPINDLE
Speed	r/min	50-4000
Max output torque	Nm	177
Steps	-	Stepless
Power	kW	15(30min)/11(Rated)
CHUCK
Diameter	inch	8″
X-axis Max Travel Speed	m/min	30
Z-axis Max Travel Speed	m/min	30
X-axis Travel	mm	200
Z-axis Travel	mm	1050
Tailstock Quill Travel	mm	100
Tailstock Quill Taper	Morse	4#
Turret Type	-	horizontal 8-station
SIZE OF TOOL
Outer Circle Cutter	mm	25×25
Boring Bar Diameter	mm	Φ40/Φ32/Φ25/Φ20
Choosing Tool at The Nearest Distance	-	Yes
MAX LOADING
Disc	kg	200
Shafts	kg	500
MACHINE WEIGHT	kg	4650
MACHINE SIZE	mm	3570 x 1860 x 1850

Characteristic

This machine tool can process shaft and disk parts, turn threads, arcs, cones and internal and external surfaces of rotating bodies, and process rotating body parts efficiently, in large quantities and with high accuracy. In the design, the rigidity of the main shaft, bed, tailstock and other components are reasonably matched, which greatly improves the rigidity of the whole machine and ensures the stability during re cutting. Therefore, the machining accuracy of this machine tool can reach IT6 ~ IT7. As a general-purpose machine tool, it is especially suitable for automobile, motor, bearing, hydraulic and other industries to process rotating parts with high efficiency, large batch and high precision.
